    High Pressure, Textile Reinforced Hydraulic Rubber Hose

    EN 854 3TE textile reinforced hydraulic hose is suitable for delivering petroleum-based hydraulic fluids and it is mainly used for medium pressure applications. It is composed of three parts: tube, reinforcement and cover. The tube is made from high quality oil resistant synthetic rubber, making the hose widely used for delivering petroleum-based hydraulic oils. The reinforcement is made from two layers of braided textile, making the hose lightweight and have excellent flexibility. What’s more, the hose is easy to operate. The cover is made from high quality black oil, weather, abrasion and corrosion synthetic rubber, making the hose have wide application and long service life.

    INNER TUBE: oil resistant synthetic nitrile rubber

    REINFORCEMENT: two layers of fibre braided

    COVER: oil and weather resistant synthetic rubber

    APPLICATION: petroleum-based hydraulic fluids under medium pressure

    SURFACE: wrapped surface , smooth surface

    TEMPERATURE RANGE: -40℃ (-104 ℉ ) to +100℃(+212 ℉)

    Specification: EN854 3TE

    Item CodeMetric SizeInch SizeSAE  Dash sizeI.DO.DMax W.PMin B.PMin B.RW.T
    (mm)(mm)
    mm inches Dash MinMaxMinMaxMpa psiMpammKg/m
    3TE-05 53/16034.4 5.2 10.0 11.6 2.5 360.0 10.0 35.0 0.12
    3TE-06 6.31/4045.9 6.9 11.6 13.2 2.5 360.0 10.0 45.0 0.13
    3TE-08 85/16057.4 8.4 13.1 14.7 2.0 290.0 8.0 65.0 0.16
    3TE-10 103/8069.0 10.0 14.7 16.3 2.0 290.0 8.0 75.0 0.18
    3TE-13 12.51/20812.1 13.3 17.7 19.7 1.6 230.0 6.4 90.0 0.23
    3TE-16 165/81015.3 16.5 21.9 23.9 1.6 230.0 6.4 115.0 0.3
    3TE-19 193/41218.2 19.8 28.0 30.0 7.0 1020.0 28.0 130.0 0.54
    3TE-25 2511624.6 26.2 34.4 37.4 5.5 800.0 22.0 150.0 0.72
    3TE-32 31.51-1/42030.8 32.8 40.8 43.8 4.5 650.0 18.0 190.0 0.88
    3TE-38 381-1/22437.1 39.1 47.6 51.6 4.0 580.0 16.0 240.0 1.07
    3TE-51 5123249.8 51.8 60.3 64.3 3.3 480.0 13.2 300.0 1.36
