    Low Pressure, Textile Reinforced Hydraulic Rubber Hose

    EN 854 1TE textile reinforced hydraulic hose is suitable for hydraulic control lines and it is mainly used to deliver hydraulic fluids. It is composed of three parts: tube, reinforcement and cover. The tube is made from high quality oil resistant synthetic rubber, making the hose can be used to deliver oils smoothly. The reinforcement is made from one layer of braided textile, making the hose lightweight, flexible and easy to operate. The cover is made from high quality oil and weather resistant synthetic rubber, making the hose have longer service life. Besides, the hose can eliminate the vibration of the hydraulic lines.

    INNER TUBE: oil resistant synthetic nitrile rubber

    REINFORCEMENT: one layer textile yarn braided

    COVER: oil and weather resistant synthetic rubber

    APPLICATION: petroleum-based hydraulic fluids under medium pressure

    SURFACE: wrapped surface , smooth surface

    TEMPERATURE RANGE: -40℃ (-104 ℉ ) to +100℃(+212 ℉)

    Item CodeMetric SizeInch SizeSAE  Dash sizeI.DO.DMax W.PMin B.PMin B.RW.T
    (mm)(mm)
    mm inches Dash MinMaxMinMaxMpa psiMpammKg/m
    1TE-05 53/16034.4 5.2 10.0 11.6 2.5 360.0 10.0 35.0 0.12
    1TE-06 6.31/4045.9 6.9 11.6 13.2 2.5 360.0 10.0 45.0 0.13
    1TE-08 85/16057.4 8.4 13.1 14.7 2.0 290.0 8.0 65.0 0.16
    1TE-10 103/8069.0 10.0 14.7 16.3 2.0 290.0 8.0 75.0 0.18
    1TE-13 12.51/20812.1 13.3 17.7 19.7 1.6 230.0 6.4 90.0 0.23
    1TE-16 165/81015.3 16.5 21.9 23.9 1.6 230.0 6.4 115.0 0.3
